Ensoniq ES1370

Same Exact card as the

  Sound Blaster PCI64

Hear sounds from all around you with the Sound Blaster PCI64.
 Designed for the home user, gamer or multimedia enthusiast, you feel every explosion and experience each spine-tingling scream.
Using up to four speakers at once, this is the only way to get true 3D sound!

PCI bus for optimal performance
The Sound Blaster PCI64 utilizes the PCI bus, allowing it to use far less CPU overhead than traditional sound cards. This translates into higher frame rates in your games, more bandwidth for 3D audio and multi-channel support for upcoming game titles.

3D Audio Technology, 64-voice Wavetable Synthesis, & 4-speaker support
Creative's digital effects engine lets you enjoy customizable audio effects such as multi-algorithm reverb and chorus. With 8- and 16-bit mono and stereo recording and playback, and user-selectable sample rates from 5kHz to 48kHz, the Sound Blaster PCI64 produces precise audio fidelity and supports 16 MIDI channels, 128 GM & GS compatible instruments and 10 drum kits. You can also connect to 2- or 4-speakers for an engulfing 3D surround-sound experience.

We only have one of these available.





Full compatibility
Sound Blaster PCI64 is a snap to install with complete plug-and-play, Windows 95 and 98 compatibility. It accurately produces high fidelity sound in any audio or game application. And, with Sound Blaster PCI compatibility, you are assured support for the largest selection of existing MS-DOS® and Windows-based titles. Full compatibility is exactly what you'll get from Creative, the leader in PC audio technology.

Features:
16-bit 48kHz Full - Duplex

Wave-table synthesis for more expressive music playback
Supports 2MB or 4MB wave-table sample sets utilizing system memory
Spatial 3D audio output for immersive 3D audio playback in supported
DirectSound games Plug and Play compliant

CD-quality audio 32-voice
PCI bus mastering interface Full support for Windows 95 Windows NT and DOS Applications
General MIDI MPC3 Plug & Play Microsoft DirectSound 3D & Derivatives
MPU-401 UART Microphone In MPC3 CD Audio In
MIDI/Joystick Port (Amplified out) Line Out (Front)/Speaker Out Line Out (Rear) (Amplified out)
Sound Blaster PCI Windows ME Auxiliary In  (Rear Out)

Minimum System Requirements:
Intel Pentium or AMD-K5T 100MHz or higher processor  Intel or 100% compatible motherboard chipset
16MB system RAM
(32MB strongly recommended)

Open, half-length PCI 2.1-compliant slot

Win 95, Win® 98, Win ME
Win NT 4.0 or Win 2000
and DOS Applications
CD-ROM drive required for software installation Headphones or self-powered speakers (not included)
Open half-length PCI 2.1 compliant slot
Ideal Entry-level PCI Audio Solution

*Usage of this product in Windows NT® 4.0 requires a minimum 200MHz processor and 32MB system RAM.
 Functionality may differ from box specifications due to limitations in Windows NT® .
Bundled application and utility software may have higher system requirements

Hardware Specifications
Frequency Response: 30Hz - 20KHz (Line-out) Signal to Noise Ratio: 90 db
Total Harmonic Distortion @ 1 Vrms (10 K Ohm load): 0.01% Microphone Impedance: 600 Ohms
Supply Voltage Requirement (Loading): +5, +12, -12 Volt Line-In Impedance: 47 K Ohms
Current Consumption (Typical): 250, 500, 50 mA respectively CD Audio-In Impedance: 50 K Ohms
Sampling Rate for Playback/Recording (Stereo): 4 KHz - 48 KHz Microphone Sensitivity: 10 - 200 mVpp
Line-In Sensitivity: 0 - 2 Vpp
AD/DA Resolution: 16 bits CD Audio-In Sensitivity: 0 - 2 Vpp

Environmental Specifications
Environment Temperature (non-operating): -40C to 70C MTBF: >60,000 hours
Environment Temperature (operating): 10C to 50C Relative Humidity (operating): 30% to 80%
Relative Humidity (non-operating): 30% to 95% Vibration: Sine wave for X, Y and Z axis (non-operating)
5Hz to 15Hz : 0.76mm (P-P)
15Hz to 25Hz : 1.5G
25Hz to 50Hz : 0.15mm (P-P)
50Hz to 100Hz : 3G
Drop Test: 30cm above concrete ground on all 6 sides

Sound Blaster PCI64 Update for x86 Windows NT 4.0     E64-NTDRV-1-US
Location of Driver:  Click Here    as of 12/23/98 Driver: e64nt4u.exe  Revision: E64-NTDRV-1-US

Shipping and handling fee $15 standard USPS (mail)
This include boxing (not double) and postage.

This is a sample of UPS Charges from Phoenix AZ to Atlanta GA
with $100 insurance included

Guaranteed by End of Day -- 2 Days    $14.88
Guaranteed by End of Day -- 3 Days    $12.86
UPS Ground
9.39

If you desire to have this sent UPS,
UPS strongly recommends that we double box these items.
We will have a Double Boxing charge that will require and additional $10.00

It is your choice on shipping


Have a question?
Can't wait for this auction to close?

Email me at ivan@phoenixoffice.com

Payment by credit card accepted through I prefer PayPal, the #1 payment service in online auctions!
We do not use Bilpoint

I prefer PayPal, the #1 payment service in online auctions!
      Click here to pay with PayPal!

Personal Checks will take an extra week to 10 days for check to clear.
